Burnt my resistor

Vertex 3D Printer Vertex - Wiring and electronics
1

Can somebody tell me the value of the resistor on the PCB board right above of the Nozzle next to the green sockets?
I managed to burn it and need to replace it so the fans will work again

2

R1 looks like 10 ohm (Brown Black Black Gold)
Sorry my eyes are not perfect.
LOL

3

I have the same problem with the eyes, but I think too Brown-Black Black-Gold :slight_smile:

sxyxlan9nuw1d.png1182×726

4

Is that a picture of your machine?
If so you should measure the resistance.
It looks ok to me.

5

Hi,

I have the same problem but i can not solder the resistor because the soldering point is not on the PCB any more. Does anyone have a schematic and PCB-Layout of the board?

Thank you?
